Damp Proofing - DPC Injection

In use by the Professional Damp Proofing Trade & DIY enthusiasts

Drill 12mm diameter hole

Inject Cream DPC

Insert a DPC Plug

Or, use our Unique ONE SHOT measured dose Skeleton Gun.


Site Index for Dampness




Site Shopping Pages


Useful Articles about Damp


Ultra DPC Cream

New, easy to install, cream DPC product - no pump required, no mess, no smell - includes injection nozzle extension. Damp proof coursing made easy - forms a continuous silicone damp proof course (DPC).

British Board of Agrèment

BBA Test Certificate No: 02/3961, as used by the professionals.

The BBA is a Government Approved organisation which has been testing building materials for over 30 years.

Note - not all damp proofing materials have passed these tests - beware of imitations).

click here for a check list to diagnose your damp


Diagnosing dampness

Call us 01626 872886

A 'damp meter' and surface thermometer (see www.dampness-info.co.uk/meters.htm) are useful tools for this diagnosis.

If not available use the back of your hand to assess the relative dampness of one affected area to another unaffected area..

click here to look at a real house Case Study

click here if you would like to read a genuine testimonial


Consumption rates - how many metres of wall will a tube of damp proofing cream inject?

Small tubes

380cc tube with extension nozzle - makes a maximum of 3.5 metres/11 feet of damp proof course in single thickness masonry (spacing interval 120mm/4.5 inch walls).

Can be applied with a DIY, standard 380cc version mastic/sealant gun or a professional 380cc skeleton gun (see our Order Form)

380cc ONE SHOT measured dose Skeleton Gun - a specially modified skeleton gun, giving one shot of cream per trigger pull, for one 4.5 inch (115mm) wall thickness.

Two pulls of the trigger for 9 inch (230mm) walls, per hole.

Large tubes

1000cc tube with extension nozzle - makes a maximum of 9 metres/30 feet of damp proof course in single thickness masonry (spacing interval 120mm/4.5 inch walls).

Requires a professional 1000cc skeleton gun (see our Order Form)

1000cc ONE SHOT measured dose Skeleton Gun - a specially modified skeleton gun, giving one shot of cream per trigger pull, for one 4.5 inch (115mm) wall thickness.

Two pulls of the trigger for 9 inch (230mm) walls, per hole.

Large tubs

3 litre bulk pack, for professionals - makes a maximum of 27 metres/90 feet of damp proof course in single thickness masonry (spacing interval 120mm/4.5 inch walls).

Requires a pump up dispenser.

Go straight to Price List in our Damp Shop


Optional Items:

- Replastering Additive (Rendaproof)

- 'Tanking' waterproofing liquid (BondAcryl)

- Certificate of Product Guarantee

- Salt Neutraliser

- Anti Mould paint

- Professional Skeleton Guns

- Professional Extension Tube (1000cc)

- Anti Dry Rot Paint


Replastering Notes:

Don't forget that replastering is essential if dampness has affected your plaster because of the 'salts' that come with the water: you have two options -either replaster to our specification using sand and cement, with Renderpruf salt inhibitor/waterproofer in the water or look at the Wall Membrane option. Wall Membranes offer a considerable improvement over sand and cement - they produce a warmer surface, can be insulated easily and can be directly plastered with lightweight, modern plasters, like Carlite Bonding.

For easy fix Membrane information go to: www.drywallandfloor.co.uk

Air Gap Membrane being fixed ready for Bonding Plaster or plasterboard

Kontract Membrane for damp  floors


How to install a damp proof course (DPC)

First, check for high ground levels, leaking gutters and downpipes, water leaks. A Damp Proof Course must be at least 6 inches (150mm)

above abutting ground level (whether internal or external), to avoid splash up or 'bridging'.

1. Drill 12mm diameter holes at 120mm intervals in the mortar course (or via the brickwork, angled down to meet the mortar course)

selected to be at least 150mm above outside or abutting ground level. Blow or vacuum holes to remove dust.

2. Fit the extension nozzle to the cartridge tube and load into the skeleton gun

3. Inject cream from the bottom of the hole outwards until the hole is full.

4. Replaster to our specification.

Treat any skirting boards or joinery with Boron Ultra Gel.

Holes can be capped with mortar or fitted with a plastic plug

Replastering to a minimum of 1.2 metres internally, to our specification, using sand and cement and Rendapruf integral waterproofer,

is required to finish the job and to prevent 'salts' damage to plaster finishes and decorations.

How Rising Dampness is Blocked

Before Treatment

After Treatment

Our Products required: Quick Cream DPC, Skeleton Gun - either a 380cc or professional 1000cc

Optional Products: Rendapruf Replastering Additive (5 litre), Wall Plugs, Boron Ultra Gel (2.5 litre), UltraProof exterior wall treatment (5 litre or 25 litre),

Anti-Mould Paint (2.5 litre), Professional Skeleton Guns (380cc or 1000cc), Professional Extension Nozzle (for repeated use with 1000cc cartridges)

Tools Required: 12mm masonry bit, electric hammer drill, eye protection

Go straight to Price List in our Damp Shop


Typical damp proofing cream usage rates:

4.5 inch thick (115mm) single leaf wall - 1000cc (1 litre) per 9 metres, inject from either side

9 inch thick wall (230mm) double leaf solid or cavity - 1000cc(1 litre) per 4.5 metres, inject from one side or from both sides.

18 inch thick wall (460mm) solid or random fill - 1000cc (1 litre) per 2 metres, inject from both sides


Damp Problems in the House - how to get rid of damp

Damp walls in houses are sometimes caused by Rising damp, but treating damp always requires careful analysis to avoid damp proofing walls that are suffering from penetrating dampness, condensation or residual 'salts'. We recommend damp proofing cream by hand injection of a new damp proof course (DPC).

If you ask for our free help we will ensure that you know how to treat damp walls properly to stop damp and if necessary how to use a Damp Meter.

You can easily use UltraCure damproofing cream to install a damp proof course, sometimes referred to as a DPC, without any special training.

In treating damp you may also need to consider some tanking, below the damp proof course, which means forming a waterproof coating to stop damp penetrating from below ground.


Other considerations- treating damp

Rising damp can be found in houses which have not been built with a damp proof course or where the damp proof course is faulty.

The signs of rising damp can include a tidemark on walls just above the skirting boards, damp patches that come and go, 'salt' marks, loose paint or wallpaper and the plaster can be cold to the touch. To stop damp of this kind we need to either install a new DPC or uncover the original damp proof course level - it may have been bridged by raised garden soil, pathways or even by the local Council in surfacing the pavements.

Rising damp is not confined to external walls. You should also examine your internal and Party walls for the telltale signs.

The problem of rising damp should be addressed as soon as possible. Lack of treatment will result in a deterioration of the masonry, plaster and any woodwork that is attached (for example, skirting boards). Another significant side-effect of damp, some authorities believe, is that the mould that it can cause is a major factor in childhood asthma.

It can certainly trigger asthma attacks! Apply one of our Anti-Mould products - Anti-Mould Cleaner, Anti-Mould Paint or use our concentrated Anti-Mold Paint Additive (works in all types of paint).
